Safety Recall Y4K: 2018-2019 Honda Odyssey Battery Terminal Inspection and Transmission Replacement

“This site contains affiliate links for which OEMDTC may be compensated”

April 12, 2019

Loose Battery Terminal Connections

A damaged parking rod can allow the vehicle to roll when parked, increasing the risk of a crash or injury.



NHTSA Campaign Number: 19V299

Manufacturer Honda (American Honda Motor Co.)

Components POWER TRAIN, ELECTRICAL SYSTEM

Potential Number of Units Affected 50,504



Summary

Honda (American Honda Motor Co.) is recalling certain 2018-2019 Odyssey vehicles. Loose battery terminal connections or a degraded battery may cause the Transmission Control Unit (TCU) to unexpectedly reboot. Upon rebooting, the TCU may shift the transmission to the “Park” position, possibly damaging the parking rod.



Remedy

Honda will notify owners, and dealers will ensure the battery terminal connections are secure and will update the TCU software, free of charge. Additionally, the parking rod effectiveness will be checked. The recall began May 31, 2019. Owners may contact Honda customer service at 1-888-234-2138. Honda’s numbers for this recall are Z4J, Y4K.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.



Check if your Honda has a Recall




Service Bulletin

A19-043
April 12, 2019
Version 1



Safety Recall: 2018-19 Odyssey Battery Terminal Inspection and Transmission Replacement



AFFECTED VEHICLES

Year Model Trim VIN Range
2018-19 Odyssey Touring, Touring-Elite Check the iN VIN status for eligibility.



BACKGROUND

A momentary voltage loss to the TCM, usually caused by a loose battery terminal, can cause the transmission to shift to Park while driving. When this happens, the parking mechanism could get damaged, and the vehicle may move while the shifter is in Park.

Honda has developed software to correct this issue. See S/B 19-046. This service bulletin provides information to replace the transmission of vehicles that were identified as having their transmission shift to Park while driving . The new transmissions come with the new software.



CUSTOMER NOTIFICATION

Owners of affected vehicles will be sent a notification of this campaign.

Do an iN VIN status inquiry to make sure the vehicle is shown as eligible.

Some vehicles affected by this campaign may be in your new or used vehicle inventory.

Failure to repair a vehicle subject to a recall or campaign may subject your dealership to claims or lawsuits from the customer or anyone else harmed as a result of such failure. To see if a vehicle in inventory is affected by this safety recall, do a VIN status inquiry before selling it.



CORRECTIVE ACTION



PARTS INFORMATION

Part Name Part Number Quantity
Reman A/T Kit (2019 models) 06200-5MX-A83RM 1
Reman A/T Kit (2018 models) 06200-5MX-A77RM 1
Flange Bolt (12 x 120) 90051-5J4-000 1
Flange Bolt (12 x 45) 90165-SDA-A00 2
Flange Bolt (12 x 85) 95701-12085-07 1
Flange Nut (12 mm) 90371-SAA-010eBay 4
Flange Bolt (10 x 35) 90163-SDA-A01 2
Flange Bolt (10 x 103) 90163-SJH-000 1
Flange Bolt (10 x 25) 90167-SAA-010 4
Self-Lock Nut (10 mm) 90212-SA5-003 Safety Recall Y4K: 2018-2019 Honda Odyssey Battery Terminal Inspection and Transmission Replacement | small light 9
Pre Chamber Gasket 18393-SDB-A00 Safety Recall Y4K: 2018-2019 Honda Odyssey Battery Terminal Inspection and Transmission Replacement | small light 1
Exhaust Pipe Gasket (NOK) 18212-SA7-003 Safety Recall Y4K: 2018-2019 Honda Odyssey Battery Terminal Inspection and Transmission Replacement | small light 2
Split Pin (3.0 x 22) 94201-30220eBay 2
Castle Nut (14 mm) 90365-STX-A00 Safety Recall Y4K: 2018-2019 Honda Odyssey Battery Terminal Inspection and Transmission Replacement | small light 2
Flange Bolt (12 x 30) 90161-SHJ-A00 8
Flange Bolt (14 x 140) 90165-TZ5-A10 2
Flange Bolt (14 x 125) 90165-TK8-A00 2
Spindle Nut 90305-S3V-A11 Safety Recall Y4K: 2018-2019 Honda Odyssey Battery Terminal Inspection and Transmission Replacement | small light 2
Snap Ring (32 x 2.2) 44319-STX-A01 Safety Recall Y4K: 2018-2019 Honda Odyssey Battery Terminal Inspection and Transmission Replacement | small light 2
Flange Bolt (10 x 30) 90163-SDB-A00 3



NOTE

An extremely small percentage of vehicles may require a new battery or battery terminals.

Part Name Part Number Quantity
Battery Plus Terminal (large) 32413-TG7-A02 1
Battery Sensor Assembly 38920-TZ5-A02 1
(L3) Johnson MSDS Battery Assembly 31500-TZ7-AGM100M 1



REQUIRED MATERIALS

Part Name Part Number Quantity
Antifreeze/Coolant Type 2 OL999-9011 Safety Recall Y4K: 2018-2019 Honda Odyssey Battery Terminal Inspection and Transmission Replacement | small light 2



TOOL INFORMATION

NOTE

The following tools are available through the Tool and Equipment Program.

Part Name Part Number Quantity
Torque Wrench (1/4″ Dr, 20-150 in/lb) Model 1501 MRH

or

Model 1501 MRPH

1
Battery Terminal Cleaner

Battery Terminal Cleaner

BTC7B 1
Engine Balance Bar VSB02C000041 1
Engine Hanger AAR-T1256 2
Subframe Adaptor VSB02C000016 1



WARRANTY CLAIM INFORMATION

The normal warranty applies.

Operation
Number
Description Flat
Rate
Time
Defect
Code
Symptom
Code
Template
ID
Failed
Part
Number
2181CJ 2018 Odyssey Replace the transmission (includes alignment and neutral position memorization). Inspect battery terminals, and check torque. 7.0 hr 6AN00 Y4K00 A19043A 28102-5MX-A610
2181CJ 2019 Odyssey Replace the transmission (includes alignment and neutral position memorization). Inspect battery terminals, and check torque. 7.0 hr 6AN00 Y4K00 A19043B 28102-5MX-A610
2181CK 2018 Odyssey Replace the transmission (includes alignment and neutral position memorization).

Repair one terminal.

7.1 hr 6AN00 Y4K00 A19043C 28102-5MX-A610
2181CK 2018 Odyssey Replace the transmission (includes alignment and neutral position memorization). Replace one terminal. 7.1 hr 6AN00 Y4K00 A19043D 28102-5MX-A610
2181CK 2019 Odyssey Replace the transmission (includes alignment and neutral position memorization).

Repair one terminal.

7.1 hr 6AN00 Y4K00 A19043E 28102-5MX-A610
2181CK 2019 Odyssey Replace the transmission (includes alignment and neutral position memorization). Replace one terminal. 7.1 hr 6AN00 Y4K00 A19043F 28102-5MX-A610
2181CL 2018 Odyssey Replace the transmission (includes alignment and neutral position memorization).

Repair both terminals.

7.5 hr 6AN00 Y4K00 A19043G 28102-5MX-A610
2181CL 2018 Odyssey Replace the transmission (includes alignment and neutral position memorization). Replace both terminals. 7.5 hr 6AN00 Y4K00 A19043H 28102-5MX-A610
2181CL 2019 Odyssey Replace the transmission (includes alignment and neutral position memorization).

Repair both terminals.

7.5 hr 6AN00 Y4K00 A19043J 28102-5MX-A610
2181CL 2019 Odyssey Replace the transmission (includes alignment and neutral position memorization). Replace both terminals. 7.5 hr 6AN00 Y4K00 A19043K 28102-5MX-A610
2181CM 2018 Odyssey Replace the transmission (includes alignment and neutral position memorization). Repair both terminals, and replace the battery (includes internal resistance reset). 8.0 hr 6AN00 Y4K00 A19043L 28102-5MX-A610
2181CM 2018 Odyssey Replace the transmission (includes alignment and neutral position memorization). Replace both terminals, and replace the battery (includes internal resistance reset). 8.0 hr 6AN00 Y4K00 A19043M 28102-5MX-A610
2181CM 2019 Odyssey Replace the transmission (includes alignment and neutral position memorization). Repair both terminals, and replace the battery. (includes internal resistance reset). 8.0 hr 6AN00 Y4K00 A19043N 28102-5MX-A610
2181CM 2019 Odyssey Replace the transmission (includes alignment and neutral position memorization). Replace both terminals, and replace the battery. (includes internal resistance reset). 8.0 hr 6AN00 Y4K00 A19043P 28102-5MX-A610



Skill Level: Repair Technician



REPAIR PROCEDURE

NOTE

Do not drain the ATF from the old transmission. The replacement (Reman) transmission comes pre-filled with ATF.

  1. Remove the engine cover.

engine cover

  1. Remove the front bulkhead cover.

front bulkhead cover

  1. Remove the air intake duct.
  2. Remove the air guide.

air intake duct

  1. Disconnect the battery terminals.

5.1 Make sure the ignition is turned to OFF.

5.2 Disconnect and isolate the negative cable with the battery sensor from the battery.

NOTES

  • Always disconnect the negative side first.
  • To prevent damage, do not hold the connector when removing the battery terminal.
  • Do not disconnect the battery sensor from the cable.

5.3 Open the terminal cover.

5.4 Disconnect the terminal from the battery.

battery sensor

  1. Remove the setting plate.
  2. Remove the battery cover.
  3. Remove the battery.
  4. Remove the battery bottom cover.
  5. Disconnect the battery fan motor connector.

battery fan motor

  1. Remove the intake air duct.
  2. Remove the air cleaner.

air cleaner

  1. Remove the skid block.
  2. Disconnect the positive cable from the starter.
  3. Remove the starter and connector.



starter

  1. Remove the battery base.
  2. Disconnect the breather tube.
  3. Disconnect the TCM connector.
  4. Remove the upper transmission mounting bolt.
  5. Disconnect the speed sensor.
  6. Remove the heater hose bracket.
  7. Remove the harness bracket bolts.

battery base

  1. Raise the vehicle on a lift.
  2. Remove the splash shield.

splash shield

  1. Drain the coolant.

25.1 Install a rubber hose on the radiator.

25.2 Loosen the drain plug, and drain the coolant.

drain plug

  1. Lower the vehicle.
  2. Disconnect the water bypass hoses from the transmission warmer.

NOTE

To prevent damage, do not bend the pipes excessively.

transmission warmer

  1. Install the engine support hanger.

NOTES

  • Be careful when working around the windshield.
  • Two sets of AAR-T1256 are required for stacking additional cross section bars.
  • Be careful not to damage the hood opener cable when installing the engine support hanger at the front bulkhead.

28.1 Remove the front damper caps.

engine support hanger

28.2 Install the engine hanger balance bar.

28.2.1 Attach the front arm to the front cylinder head with a commercially available spacer and a 10 x 1.25 mm bolt.

28.2.2 Attach the rear arm to the rear cylinder head with a commercially available spacer and a 10 x 1.25 mm bolt.

28.3 Install the engine support hanger as shown, and attach the hook to the slotted hole in the engine hanger balance bar. Tighten the wing nut by hand, and lift and support the engine/transmission.

  1. Remove coil number 6.

coil number 6

  1. Remove the front engine mount stop and front engine mount mounting bolt.

front engine mount stop

  1. Remove the rear engine mount stop, heat shield, and rear engine mount mounting bolt.

rear engine mount stop

  1. Disconnect the steering joint.

NOTE

Be careful not to pull out the lower shaft from the upper shaft. If it separates, use the aligning paint or stamped marks on the shafts to align them.

aligning paint or stamped marks

  1. Lift the vehicle.
  2. Remove both front wheels.

Remove both front wheels

  1. Remove the transmission undercover.

transmission undercover

  1. Disconnect the front ACM (active control engine mount) sub harness.

ACM (active control engine mount)

  1. Remove the front subframe stiffener plate.

front subframe stiffener plate

  1. Remove the under-floor TWC and exhaust pipe.

TWC and exhaust pipe

  1. Disconnect the EPS motor control unit connector.

EPS motor control unit connector

  1. Disconnect both tie rod end ball joints.

40.1 Remove the cotter pin.

40.2 Remove the nut.

40.3 Disconnect the tie-rod end ball joint from the knuckle using a ball joint thread protector and a ball joint remover.

NOTES

  • Be careful not to damage the ball joint boot when using the ball joint remover.
  • During installation, install the new cotter pin after tightening the nut, and bend its end as shown.

ball joint remover

  1. Disconnect both lower stabilizer links.

41.1 Remove the flange nuts while holding the respective joint pin with a hex wrench.

41.2 Remove the stabilizer link.

NOTE

The stabilizer link has a paint mark. The left stabilizer link is marked with green paint, and the right stabilizer link is marked with blue paint.

paint mark

  1. Remove the transmission mount.

transmission mount

  1. Install the front subframe adapter tool.

43.1 Attach the subframe adapter to the front subframe by looping the belt over the front of the front subframe, then secure the belt with its stop, and tighten the wing nut.

43.2 Raise a transmission jack, line up the slots in the subframe adapter arms with the bolt holes on the transmission jack base, then securely attach them with four bolts.

belt

  1. Remove the front subframe.

NOTES

During installation do the following:

  • After loosening the subframe bolts, be sure to replace them with new ones.
  • Lift the subframe up to the body, and loosely install the new subfrarme mounting bolts, new front stiffener mounting bolts, front stiffeners, new rear stiffener mounting bolts, and rear stiffeners.
  • Tighten the subframe mounting bolts to the torque specification as shown.
  • Check all of the subframe mounting bolts, and tighten them if necessary.

front subframe

  1. Support the transmission with a transmission jack.
  2. Disconnect both lower arm ball joints.

46.1 Remove the lock pin from the lower arm ball joint.

NOTE

During installation, install the lock pin as shown after tightening the castle nut.

46.2 Remove the castle nut.

NOTES

  • Use a new castle nut when installing.
  • Torque the castle nut to the lower torque specification, then tighten it only far enough to align the slot with the ball joint pin hole. Do not align the castle nut by loosening it.

46.3 Disconnect the lower ball joint from the knuckle using the ball joint thread protector and the ball joint remover.

NOTES

  • Be careful not to damage the ball joint boot when installing the ball joint remover.
  • During installation do the following:
    • Be careful not to damage the ball joint boot when connecting the knuckle.
    • Degrease the ball joint before connecting the threaded section and the tapered portion of the ball joint pin, the ball joint connecting hole, the threaded section, and the mating surfaces of the castle nut.

ball joint remover

  1. Disconnect both inner driveline joints.

NOTES

Secure the driveshaft to the body on both sides with a nylon strap.

47.1.1 Pry the inboard joint using a pry bar.

NOTE

Be careful to not damage the oil seal or the end of the inboard joint with a pry bar.

47.1.2 Remove the driveshaft as an assembly.

NOTE

Do not pull on the driveshaft, because the inboard joint may come apart. Pull the inboard joint straight out to avoid damaging the oil seal.

47.2.1 Drive the inboard joint off of the intermediate shaft using a drift punch and a hammer.

47.2.2 Remove the driveshaft as an assembly.

NOTES

  • Do not pull on the driveshaft, because the inboard joint may come apart. Pull the inboard joint straight out.
  • Use new snap rings when installing the driveshaft.

Remove the driveshaft as an assembly

  1. Remove the intermediate shaft assembly.

intermediate shaft assembly

  1. Disconnect the CKP sensor connector.

CKP sensor connector

  1. Remove the front engine mount bracket.

front engine mount bracket

  1. Disconnect the transmission ground strap.
  2. Remove the torque converter cover.
  3. Remove the torque converter bolts.
  4. Remove the remaining transmission mounting bolts.
  5. Remove the transmission.
  6. Remove the dowel pins, and install them on the new transmission.

dowel pins

  1. Install the new transmission.
  2. Install all removed parts in the reverse order of removal except the intake air duct and the front bulkhead cover. The battery terminals will still need to be inspected.

NOTES

  • Make sure to replace all must-replace parts.
  • The reman transmission is prefilled with ATF. It does not need to be filled.
  • Use new snap rings when installing the drivelines.
  1. Fill the cooling system with coolant.

At coolant change: 7.4 L (1.90 US gal) with coolant reservoir included.

  1. Do the keyless access registration.
  2. Go to BATTERY TERMINAL INSPECTION.



.

BATTERY TERMINAL INSPECTION

  1. Inspect the positive and negative battery terminals.

NOTICE

  • Battery terminal installation on this vehicle is critical. Failure to follow the terminal installation or inspection procedures could cause electrical problems, stalling, and/or DTCs to set. Do not over torque the terminals, and do not use an impact gun.
  • Battery terminal installation must be level or below the post. See GOOD and NO GOOD example pictures.

Compare both of the battery terminals to the examples below.

battery terminals

Do the battery terminals look like the good example?

Yes – Go to step 2.

No – Go to TERMINAL REPAIR.

  1. While holding down the terminal, torque both positive and negative clamps to 4-6 N•m (35-53 lb-in).

NOTE

Do not over torque the terminal.

torque both positive and negative clamps

  1. Make sure the connection is tight by wiggling the terminals back and forth.

Make sure the connection is tight

Are both terminals secure?

Yes – Apply multipurpose grease to the terminals to prevent corrosion, and install the air intake duct and the bulkhead cover. Then, do the following steps:

3.1 Check the front-end alignment.

3.2 Do the VSA Sensor Neutral Position Memorization procedure.

3.3 Test-drive the vehicle, and confirm the repair.

No – Go to TERMINAL REPAIR.



.

TERMINAL REPAIR

  1. Remove the terminal or terminals, and clean the post using an approved battery terminal cleaner or equivalent.

battery terminal cleaner

1.1 Make sure the ignition is turned to OFF.

1.2 Disconnect and isolate the negative cable with the battery sensor from the battery.

NOTES

  • Always disconnect the negative side first.
  • To prevent damage to the connector, do not hold it when removing the battery terminal.
  • Do not disconnect the battery sensor from the cable.

1.3 Open the terminal cover.

1.4 Disconnect the terminal from the battery.

battery sensor

  1. While holding down the terminal, torque both positive and negative clamps to 4-6 N•m (35-53 lb-in).

NOTES

  • Do not over torque the terminal.
  • Always connect the positive side first.

torque both positive and negative clamps

  1. Compare both of the battery terminals to the examples below.

Compare both of the battery terminals

Do the battery terminals look like the good example?

Yes – Go to step 4.

No – Go to REPLACE BATTERY TERMINAL.

  1. Make sure the connection is tight by wiggling the terminals back and forth.

Make sure the connection is tight

Are both terminals secure?

Yes – Apply multipurpose grease to the terminals to prevent corrosion, and install the air intake duct and the bulkhead cover. Then do the following steps:

  • Check the front-end alignment.
  • Do the VSA Sensor Neutral Position Memorization procedure.
  • Test-drive the vehicle, and confirm the repair.

No – Go to REPLACE BATTERY TERMINAL.



.

REPLACE BATTERY TERMINAL

  1. Remove the battery terminal that does not sit at or below the top of the post.
  2. Install a new terminal, and torque the terminal and clamp nut to 4-6 N•m (35-53 lb-in) while holding it down.

NOTES

  • Always disconnect the negative side first.
  • To prevent damage, do not hold the connector when removing the battery terminal.
  • Do not disconnect the battery sensor from the cable.
  1. Compare both of the battery terminals to the examples below.

Compare both of the battery terminals

Do the battery terminals look like the good example?

Yes – Go to step 4.

No – Go to BATTERY REPLACEMENT, BATTERY RESISTANCE RESET PROCEDURE.

  1. Make sure the connection is tight by wiggling the terminals back and forth.

Make sure the connection is tight

Are both terminals secure?

Yes – Apply multipurpose grease to the terminals to prevent corrosion, and install the air intake duct and the bulkhead cover. Then, go do the following steps:

  • Check the front-end alignment.
  • Do the VSA Sensor Neutral Position Memorization procedure.
  • Test-drive the vehicle, and confirm the repair.

No – Go to BATTERY REPLACEMENT, BATTERY RESISTANCE RESET PROCEDURE.



.

BATTERY REPLACEMENT, BATTERY RESISTANCE RESET PROCEDURE

  1. Disconnect the battery terminals.

1.1 Make sure the ignition is turned to OFF.

1.2 Disconnect and isolate the negative cable with the battery sensor from the battery.

NOTES

  • Always disconnect the negative side first.
  • To prevent damage to the connector, do not hold it when removing the battery terminal.
  • Do not disconnect the battery sensor from the cable.

1.3 Open the terminal cover.

1.4 Disconnect the terminal from the battery.

battery sensor

  1. Remove the setting plate.
  2. Remove the battery cover.
  3. Remove the battery.

battery

  1. Install a new battery. Then reinstall the battery cover, and the setting plate in the reverse order of removal.
  2. While holding down the terminal, torque both positive and negative clamps to 4-6 N•m (35-53 lb-in).

NOTES

  • Do not over torque the terminal.
  • Always connect the positive side first.

torque both positive and negative clamps

  1. Compare both of the battery terminals to the examples below.

Compare both of the battery terminals

Do the battery terminals look like the good example?

Yes – Go to step 8.

No – Remove the terminal, and reinstall the terminals, then go to step 7.

  1. Make sure the connection is tight by wiggling the terminals back and forth.

Make sure the connection is tight

Are both terminals secure?

Yes – Apply multipurpose grease to the terminals to prevent corrosion, and install the air intake duct and the bulkhead cover. Then go to BATTERY INTERNAL RESISTANCE RESET.

No – Remove and reinstall the terminals, then go to BATTERY INTERNAL RESISTANCE RESET.



.

BATTERY INTERNAL RESISTANCE RESET

NOTE

Do this procedure only if the battery was replaced.

  1. Make sure all electrical systems (A/C, audio, lights, etc) are turned off.
  2. Turn the ignition to OFF.
  3. Turn the ignition to ACCESSORY.
  4. Turn the ignition to ON.
  5. Start the engine, and let it idle for 1 minute or more.
  6. Turn the ignition to OFF.
  7. Repeat steps 3 thru 6 at least four times.

NOTE

The internal resistance of the battery may not be updated if the engine starts up immediately from the OFF position.

It has to go through the ACCESSORY and ON position.

  1. Turn the ignition to ON.
  2. Connect the i-HDS and select PGM-FI.
  3. Check IDLE STOP INHIBIT (BATTERY DETERIORATION) in the Data List.

Normal – The battery internal resistance test is complete.

INHIBITED – Replace the battery, then do the battery internal resistance reset procedure again.

  1. Turn the ignition to OFF, and disconnect the i-HDS.
  2. Check the front-end alignment.
  3. Do the VSA Sensor Neutral Position Memorization procedure.
  4. Test-drive the vehicle, and confirm the repair.

END


2 Affected Products

Vehicle

MAKE MODEL YEAR
HONDA ODYSSEY 2018-2019




16 Associated Documents

Remedy Instructions and TSB

RCRIT-19V299-2354.pdf 4846.634KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [4.62 MB]




Chronology

RMISC-19V299-0249.pdf 12.829KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [12.53 KB]




Recall Acknowledgement

RCAK-19V299-8161.pdf 384.163KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [375.16 KB]




DEFECT INFORMATION REPORT

RMISC-19V299-2515.pdf 149.435KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [145.93 KB]




Defect Notice 573 Report

RCLRPT-19V299-5941.PDF 213.779KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [208.77 KB]




Manufacturer Notices(to Dealers,etc) – April 12, 2019

RCMN-19V299-3846.pdf 213.823KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [208.81 KB]




Remedy Instructions and TSB

RCRIT-19V299-1782.pdf 4784.157KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [4.56 MB]




Remedy Instructions and TSB

RCRIT-19V299-2603.pdf 3289.759KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [3.14 MB]




Remedy Instructions and TSB

RCRIT-19V299-3867.pdf 4812.272KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [4.59 MB]




ISSUED Owner Notification Letter(Part 577) – Owner Notification Letter (Z4J

RCONL-19V299-8652.pdf 112.541KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [109.90 KB]




ISSUED Owner Notification Letter(Part 577) – Owner Notification Letter (Y4K)

RCONL-19V299-3310.pdf 310.358KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [303.08 KB]




Remedy Instructions and TSB

RCRIT-19V299-5197.pdf 5506.941KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [5.25 MB]




Statement by American Honda Regarding Transmission Control Unit Software Recall: 2018-2019 Honda Odyssey Touring and Touring Elite

RMISC-19V299-0933.pdf 74.873KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [73.12 KB]




Recall Quarterly Report #1, 2019-2

RCLQRT-19V299-4154.PDF 211.153KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [206.20 KB]




Recall Quarterly Report #3, 2019-4

RCLQRT-19V299-3346.PDF 211.354KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [206.40 KB]




Recall Quarterly Report #2, 2019-3

RCLQRT-19V299-1258.PDF 211.256KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [206.30 KB]




Latest Recalls Documents

https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=19V299&docType=RCL






Bestseller No. 1
Honda Genuine COOLANT (Type-2) (OL999-9011)
  • Extended life formulation 5 years/60,000 miles
  • Better cooling performance
  • Performance under extreme operating conditions -34º to 228ºF
  • Pre-mixed DO NOT add water
  • Contains NO silcate and borates
Bestseller No. 2
PEAK OET Extended Life Blue 50/50 Prediluted Antifreeze/Coolant for Asian Vehicles, 1 Gal.
  • 1 GALLON ENGINE ANTIFREEZE/COOLANT: Fully compatible with other extended life antifreeze/coolants. This item contains a bittering agent called Denatonium Benzoate.
  • PROTECTS: Advanced formulation prevents rust & corrosion protecting all engine cooling system components
  • DESIGNED FOR ASIAN VEHICLES: Recommended for use with Acura, Honda, Infiniti, Mitsubishi, Nissan, Subaru, and Suzuki vehicles that require a BLUE Phosphate-enhanced Organic Acid Technology (POAT) formula
  • GUARANTEED: When installed as part of a complete flush and fill, PEAK guarantees this coolant will provide service life protection of up to 150,000 miles or 5 years.
  • 50/50 PREDILUTED FOR QUICK TOP OFFS: Already diluted to make topping off your cooling system a breeze
Bestseller No. 3
Honda 08C50-C321S02 Coolant Ready to Use, 2 quart
  • Honda 08C50-C321S02 coolant replaced 08C50-C321S01
  • Newer formula
  • Type 2 ready to use 50/50 blend
  • Genuine OEM Honda
  • Use for any motorcycle, ATV, UTV, snowmobile, etc
Bestseller No. 4
Zerex Asian Vehicle Blue Silicate and Borate Free 50/50 Prediluted Ready-to-Use Antifreeze/Coolant 1 GA
  • 5 year/150, 000 mile . Silicate-free, long-life, phosphate Hybrid Organic Acid Technology chemistry
  • Formulated to replace the OEM fluid in Asian make vehicles such as Honda, Nissan, KIA, Hyundai and others requiring a blue, silicate free HOAT antifreeze/coolant
  • The long life formula provides protection for all cooling system metals from rust and corrosion. The silicate free, borate free formula helps protect against harmful scale and deposits
  • Meets the following OEM and industry specifications: Hyundai/KIA MS 591-08, Mitsubishi ES-64217, JIS K 2234-1994, Ford WSS-M97B55-A, ASTM 3306, ASTM D4985, Federal Specification A-A-870A
  • Contains 30 – 50 ppm of denatonium benzoate as a bittering agent
Bestseller No. 5
Honda 08C50-C321S02 Coolant Ready to Use, 1 quart
  • Newer formula
  • 50/50 blend ready to use
  • Genuine OEM Honda
  • Use for any motorcycle, ATV, UTV, snowmobile, etc.
  • CONTAINS: Water 7732-18-5, Ethylene Glycol 107-21-1, Diethylene Glycol 111-46-6. Proprietary Inhibitors (NJTSRN217).
SaleBestseller No. 6
Valvoline Multi-Vehicle 50/50 Prediluted Ready-to-Use Antifreeze/Coolant 1 GA, light yellow/green.
  • CONTAINS ALUGARD PLUS FOR COMPATIBLITY WITH ALL ETHYLNE GLYCOL-BASED COOLANTS in automobiles and light duty trucks.Fit Type: Universal
  • FIGHTS CORROSION, SCALING AND RUST while protecting all cooling system metals (including aluminum)
  • HIGH-QUALITY ADDITIVES PROTECT AGAINST LEAKS and won’t harm gaskets, hoses, plastics or original vehicle finish
  • PRE-MIXED YELLOW FORMULA IS READY-TO-USE in a 50/50 ratio with deionized water to protect all modern engine components from winter freezing (-34F) and summer boiling (265F).
  • To use it in all makes and models designed to use ASTM D3306
Bestseller No. 7
CYCLEMAX Six Pack for Honda HP Coolant 50/50 Blend 08C50-C321S02 Contains Six Quarts and a Funnel
  • OUR CYCLEMAX PACK CONTAINS: Six Quarts for Honda HP Coolant 50/50 Blend 08C50-C321S02 along with a Convenient Disposable Funnel
  • QUALITY YOU CAN COUNT ON: Includes premium quality products to provide exceptional performance and protection for your Honda engine.
  • COMPATIBILITY AND CONVENIENCE: Developed specifically for use in aluminum engines. It uses high-tech organic Non-Abrasive Corrosion Inhibitor instead of silicates for maximum protection. Advanced Type-2 Blue formula is 100% compatible with and replaces the original Green coolant. Protects from -34 °F freeze point to 265 °F (at 15 PSI) boiling point. Ready to use straight from the bottle 50/50 blend.
  • SPECIAL NOTE: For safety purposes, this product contains a bittering agent. This product contains 43-49% Ethylene Glycol by weight.
Bestseller No. 8
CYCLEMAX Four Pack for Honda HP Coolant 50/50 Blend 08C50-C321S02 Contains Four Quarts and a Funnel
  • OUR CYCLEMAX PACK CONTAINS: Four Quarts for Honda HP Coolant 50/50 Blend 08C50-C321S02 along with a Convenient Disposable Funnel
  • QUALITY YOU CAN COUNT ON: Includes premium quality products to provide exceptional performance and protection for your Honda engine.
  • COMPATIBILITY AND CONVENIENCE: Developed specifically for use in aluminum engines. It uses high-tech organic Non-Abrasive Corrosion Inhibitor instead of silicates for maximum protection. Advanced Type-2 Blue formula is 100% compatible with and replaces the original Green coolant. Protects from -34 °F freeze point to 265 °F (at 15 PSI) boiling point. Ready to use straight from the bottle 50/50 blend.
  • SPECIAL NOTE: For safety purposes, this product contains a bittering agent. This product contains 43-49% Ethylene Glycol by weight.
Bestseller No. 9
EPAuto Spill Proof Radiator Coolant Filling Funnel Kit
  • Allows color matching of caps for dedicated adapters.
  • Cooling System fill kit prevents spills and trapped air. Trapped air pockets may cause erratic cooling system and heater performance.
  • 5” Extension Bar and 45° Elbow allow access to caps under shrouds or at an angle.
  • USPTO Patent No: US10519019B2
Bestseller No. 10
CYCLEMAX Two Pack for Honda HP Coolant 50/50 Blend 08C50-C321S02 Contains Two Quarts and a Funnel
  • OUR CYCLEMAX PACK CONTAINS: Two Quarts for Honda HP Coolant 50/50 Blend 08C50-C321S02 along with a Convenient Disposable Funnel
  • QUALITY YOU CAN COUNT ON: Includes premium quality products to provide exceptional performance and protection for your Honda engine.
  • COMPATIBILITY AND CONVENIENCE: Developed specifically for use in aluminum engines. It uses high-tech organic Non-Abrasive Corrosion Inhibitor instead of silicates for maximum protection. Advanced Type-2 Blue formula is 100% compatible with and replaces the original Green coolant. Protects from -34 °F freeze point to 265 °F (at 15 PSI) boiling point. Ready to use straight from the bottle 50/50 blend.
  • SPECIAL NOTE: For safety purposes, this product contains a bittering agent. This product contains 43-49% Ethylene Glycol by weight.

Last update on 2024-06-23 / Affiliate links / Images from Amazon Product Advertising API

This product presentation was made with AAWP plugin.

Leave a Comment

Share to...
