Transmission End Cover Leaks (9-Speed A/T) – 2015-2017 Acura TLX & 2016-2017 MDX

B15-039
September 17, 2018
10076 Version 4



Transmission End Cover Leaks (9-Speed A/T)

Supersedes 15-039, dated September 9, 2017, to revise the information highlighted in yellow



AFFECTED VEHICLES

Year	Model	Trim	VIN Range
2016-17	MDX	ALL with 9-speed A/T	ALL
2018	MDX	AWD	5J8YD4H..JL000001 thru 5J8YD4H..JL028339
2019	MDX	2WD	5J8YD3H..KL000008 thru 5J8YD3H..KL000552
2015-18	TLX	ALL with 9-speed A/T	ALL
2019	TLX AWD	9-speed A/T	19UUB3F..KA000002 thru19UUB3F..KA002947
2019	TLX 2WD	9-speed A/T	19UUB2F..KA000001 thru 19UUB2F..KA003475



REVISION SUMMARY

Under AFFECTED VEHICLES, 2018-19 MDX, and TLX were added.



SYMPTOM

The transmission end cover leaks on vehicles with 9-speed A/T.



POSSIBLE CAUSES

During assembly, the transmission end cover sealing gasket gets torn.



CORRECTIVE ACTION

Replace the transmission end cover sealing gasket.



REQUIRED MATERIALS

Part Name	Part Number		Quantity
ATF Type 3.1	08200-9017A		1



PARTS INFORMATION

Part Name	Part Number	Quantity
End Cover Kit: (contains11 Torx bolts, cover, seal, and plugs)	06233-5J4-000	1



WARRANTY CLAIM INFORMATION

The normal warranty applies.



WARRANTY CLAIM INFORMATION (TLX)

Operation Number	Description	Flat Rate Time	Template ID	Failed Part Number
2321S2	Replace the transmission end cover sealing gasket (TLX) (includes ATF level check).	1.1 hrs	15-039N	20021-5L9-053



WARRANTY CLAIM INFORMATION (MDX)

Operation Number	Description	Flat Rate Time	Template ID	Failed Part Number
2321S2	Replace the transmission end cover sealing gasket (MDX) (includes ATF level check).	1.0 hrs	15-039P	20021-5NB-043



Defect Code: 07408
Symptom Code: 05103
Skill Level: Repair Technician



REPAIR PROCEDURE

1. Raise the vehicle on a lift.
2. TLX Only: Remove the undercover.

3. Loosen and remove the fender liner as needed to access the transmission end cover.

4. Use a strap to hold the fender liner out of the way.
5. TLX Only: Remove the resonator box and move the intake tube.

6. Remove the 11 T-30 Torx bolts from the end cover.

7. Replace the cover, the sealing gasket, and bolts with the new ones from the kit. Torque the bolts to 10.0 N·m (7 lb-ft) in the sequence shown.

8. TLX Only: Reinstall the resonator box, intake tube, and undercover.
9. Reinstall the fender liner.



ATF LEVEL CHECK

Before You Start

1. Connect the i-HDS. Go to the A/T Data List, and scroll down to ATF Temperature.
2. Raise the vehicle on a lift, remove the engine undercovers (if needed), and slightly loosen the level plug.
3. Enter VSA Maintenance Mode

NOTE: You must enter this mode to complete the ATF level check; it disables the VSA and TCS functions. Be sure to complete all of the following steps within 30 seconds, or you’ll need to start over.

4. Turn the ignition to ON.
5. Press and hold the brake pedal, and release the parking brake.
6. Press and hold the VSA OFF switch until the VSA OFF indicator comes on. Then, press the switch again until the indicator goes out.
7. Release the brake pedal, and set the parking brake.
8. Press and hold the VSA OFF switch until the VSA OFF indicator comes on. Then, press the switch again until the indicator goes out.
9. Press and hold the brake pedal.
10. Press the VSA OFF switch. If the VSA OFF indicator comes on, press the switch again and release it. If successful, the VSA OFF indicator starts blinking and the VSA indicator comes on. You are now in VSA maintenance mode. To exit this mode, either turn the ignition switch to OFF or quickly press and release the VSA OFF switch, making sure the VSA OFF and VSA indicators go out.



Check the ATF Level

11. Start the engine, and wait for the transmission temperature to reach 90°F.

NOTE: If the temperature is more than 115°F (the vehicle may have been recently driven), shut off the engine and let the transmission cool down before continuing.

12. Shift to Drive, then press the D/S button again to enter sequential mode.
13. Using the paddle shifters, shift to 1st, 2nd, 3rd, then 4th Then, shift back to 3rd, 2nd, and 1st gear.

IMPORTANT: Do not shift past 4th gear with the vehicle on the lift; you could damage the transmission.

14. Apply the brakes to stop the wheels from spinning, then shift to Park.
15. Raise the engine speed to 2,000 rpm for about 5 seconds, then release the accelerator pedal. Repeat this until the transmission temperature reaches about 100°F, then wait for the temperature to reach 104 to 115°F.

NOTE: The ideal temperature for checking the ATF level is 104°F. If it’s more than 115°F, shut off the engine, let the transmission cool down, and start over again.

16. With the engine running, remove the level plug.

IMPORTANT: With the level plug removed, you must keep the engine running. If you shut it off, the ATF will pour out of the transmission.

• If a small amount of ATF trickles out of the level plug hole and keeps doing so, the level is OK. Install a new level plug, and torque it to 35 N·m (26 lb-ft).
• If no ATF comes out, loosely install a new level plug and lower the vehicle. Remove the fill plug, and add the appropriate amount of ATF Type 3.1 through the fill plug hole. Then, install a new fill plug, and check the ATF level again by removing the level plug. Be sure to monitor the ATF temperature while doing this. When you’re done, install the level plug, then torque the level and fill plugs to 35 N·m (26 lb-ft).

17. Install the engine undercovers (if removed).
18. Turn the engine off.



END

---
