KH1 – Safety Recall: 2017 Honda CR-V Rear Fuel Feed Pipe Leaks

“This site contains affiliate links for which OEMDTC may be compensated”

NHTSA Campaign Number: 17V442
Manufacturer Honda (American Honda Motor Co.)
Components FUEL SYSTEM, GASOLINE
Potential Number of Units Affected 24,127



Fuel Supply Pipe may Disconnect and Leak

If the pipe disconnects, the engine will stall, increasing the risk of a crash. Additionally, the disconnected pipe may leak fuel, which, in the presence of an ignition source, can increase the risk of a fire.



Summary

Honda (American Honda Motor Co.) is recalling certain 2017 Honda CR-V 2WD and AWD vehicles.

The affected vehicles have a fuel supply pipe that may have been improperly manufactured, possibly resulting in the pipe disconnecting and leaking while driving.



Remedy

Honda will notify owners, and dealers will replace the fuel supply pipe, free of charge.

The recall is expected to begin August 25, 2017.

Owners may contact Honda customer service at 1-888-234-2138.

Honda’s number for this recall is KH1.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY

1-800-424-9153), or go to www.safercar.gov.



Check if your Honda has a Recall



A17-062
July 14, 2017
06984 Version 2



Safety Recall: 2017 CR-V Rear Fuel Feed Pipe Leaks



AFFECTED VEHICLES

Year Model Trim VIN Range
2017 CR-V 1.5 L and 2.4 L Check the iN VIN status for eligibility.



BACKGROUND

Some fuel feed pipes were not manufactured to specification. The connector between the fuel feed pipe and the fuel line may come loose when the fuel line is pressurized. If the fuel line comes loose, it may result in leaking fuel, which, in the presence of an ignition source, may increase the risk of a fire. A loose fuel line may also cut off fuel to the engine and cause it to stall, which may increase the risk of a crash.



CUSTOMER NOTIFICATION

Owners of affected vehicles will be sent a notification of this campaign.

Do an iN VIN status inquiry to make sure the vehicle is shown as eligible.

Some vehicles affected by this campaign may be in your new or used vehicle inventory.

Failure to repair a vehicle subject to a recall or campaign may subject your dealership to claims or lawsuits from the customer or anyone else harmed as a result of such failure. To see if a vehicle in inventory is affected by this safety recall, do a VIN status inquiry before selling it.



CORRECTIVE ACTION

Replace the fuel feed pipe using two new retainers.



PARTS INFORMATION

Part Name Part Number Quantity
Fuel Feed Pipe 17700-TLA-A01 1
Retainer:
White (Sanoh) 17711-ST0-004 KH1 - Safety Recall: 2017 Honda CR-V Rear Fuel Feed Pipe Leaks | small light 1
Blue-green (Tokai) 17711-S0X-931 KH1 - Safety Recall: 2017 Honda CR-V Rear Fuel Feed Pipe Leaks | small light 1



WARRANTY CLAIM INFORMATION

Operation Number Description Flat Rate Time Defect Code Symptom Code Template ID Failed Part Number
3101GJ Replace the fuel feed pipe. 1.2 hrs 6FF00 KH100 A17062A 17700-TLA-A01



Skill Level: Repair Technician



REPAIR PROCEDURE

NOTE:

  • Flammable – Keep away from fire. If fuel ignites, it will cause a serious incident.
  • Relieve the fuel pressure before disconnecting the fuel line to avoid the risk of spraying pressurized fuel.
  • Disconnect the 12 volt battery negative terminal before disconnecting the electrical connector to reduce the risk of a fire caused by sparks.
  • Do not apply brake fluid, engine coolant, plant-based oil, or alcohol-based oil to the O-ring. Incorrect fluid or oil may cause the material to deteriorate or other damage.
  1. Relieve the fuel pressure. Refer to the service information.
  2. Do the battery disconnection procedure to disconnect the negative battery cable. Make sure to isolate it so it doesn’t unintentionally spark.
  3. 1.5 L Models only: Remove the intake air resonator.

intake air resonator



  1. Remove the fuel hose cover, then disconnect the fuel feed pipe quick-connect fitting.

quick-connect fitting



  1. Release the two brake line clips on the firewall.

brake line clips



  1. Remove the heater hose bracket at the firewall.

heater hose bracket



  1. Release the engine harness cable clamp by removing the nut.

engine harness cable clamp



  1. Remove the fuel feed pipe stay as shown.

fuel feed pipe stay



  1. Remove the fuel feed hose bracket that is located by the firewall.

fuel feed hose bracket



  1. Remove the middle floor undercover to access the fuel feed pipe connection.

middle floor undercover



  1. Disconnect the fuel feed pipe quick-connect fitting and disconnect the fuel feed pipe.

quick-connect fitting



  1. Remove the fuel feed pipe from the holders.

fuel feed pipe



  1. Remove the fuel feed pipe from the engine compartment.

NOTE: You may have to twist the fuel feed pipe to remove it from the vehicle.

fuel feed pipe



  1. Check that the connection points are clean, then install the new fuel feed pipe using the new retainers. Make sure the connections are secure and the tabs are firmly locked into place. Visually check each connection and also pull on the connector.

Make sure the connections are secure and the tabs are firmly locked into place



  1. Reconnect the battery.
  2. Check for fuel leaks by turning the vehicle to ON, but do not start the engine. After the fuel pump runs for about 2 seconds, the fuel line will be pressurized. Repeat this 2-3 times, then check that the connections are secure and that there are no leaks or rattles.
  3. Reinstall the remaining parts in the reverse order of removal.
  4. Permanently damage the original fuel feed pipe by bending or breaking it to ensure it cannot be reused.
  5. For California residents only: Fill out a Vehicle Emissions Recall – Proof of Correction certificate, and use KH1 as the recall number. Give the certificate to your customer, and advise them to keep it as proof that the recall was completed. Your customer will need to submit this certificate to the DMV only if the DMV requests it. If you need more certificates, use reorder number Y0657.

KH1



END
