B15-006
May 17, 2016
01327 Version 2
Clunk From Front Suspension When Driving at Low Speed Over Bumps or Turning
Supersedes 15-006, dated January 16, 2015, to revise the information highlighted in yellow.
AFFECTED VEHICLES
Year | Model | Trim | VIN range |
2015 | TLX | L4 | 19UUB1F..FA000001 thru 19UUB1F..FA005784 |
2015 | TLX | V6 without SH-AWD | 19UUB2F..FA000001 thru 19UUB2F..FA008008 |
2015 | TLX | V6 with SH-AWD | 19UUB3F..FA000001 thru 19UUB3F..FA001079 |
REVISION SUMMARY
Under AFFECTED VEHICLES, VIN ranges were updated.
SYMPTOM
There is a clunk from the front of the vehicle when driving at low speed while going over bumps or turning.
POSSIBLE CAUSES
At least one of the self-locking nuts at the top of the front damper/spring assemblies is loose.
CORRECTIVE ACTION
Torque both of the front damper self-locking nuts.
TOOL INFORMATION
Tool Name | Part Number | Quantity | |||
---|---|---|---|---|---|
Strut Nut Adapter | 07AAA-SVAA100 | 1 |
WARRANTY CLAIM INFORMATION
The normal warranty applies.
Operation Number | Description | Flat Rate Time | Defect Code | Symptom Code | Template IDFailed Part Number | |||
---|---|---|---|---|---|---|---|---|
4145A3 | Torque both of the front damper self-locking nuts. | 0.3 hour | 06201 | 04201 | 15-006N | 51611-TZ4-A02 |
Skill Level: Repair Technician
DIAGNOSIS AND REPAIR PROCEDURE
- Remove the nut covers at the top of both front damper assemblies.
- Torque the two self-locking nuts located at the top of the front damper/spring assemblies using a 6 mm hex wrench, a 17 mm socket, a strut nut adapter, and a torque wrench set to 70 N·m (52 ft-lb).
END
B15-006
May 17, 2016
https://static.nhtsa.gov/odi/tsbs/2016/SB-10083969-2280.pdf
- [COMPATIABLE WITH] Fit for Honda Civic 2001-2005 (Not for SI models)
- [KIT INCLUDES] 1x Front Lower Right Control Arm, 1x Front Lower Left Control Arm, 2x Front Lower Ball Joints, 1x Front Left Stabilizer Bar End Link, 1x Front Right Stabilizer Bar End Link, 2x Front Outer Tie Rod Ends
- [ENHANCEDE STRUCTURAL STRENGTH] High-strength structure can withstand repeated impact loads, making it more stable during operation. Increased driving comfort due to vibration damping
- [PREMIUM BALL JOINTS] For noise-free, articulation and durability, we sourced premium ball joints for our tubular upper control arms.
- [HIGH QUALITY] Control arms with strong torsional resistance, good stability, better response to wear and fatigue, and long service life. Precise individual steering behavior which increases driving safety
- Suspension Kit Replacement for 2011 2012 2013 2014 2015 2016 2017 Honda Odyssey
- Kit Includes: 2x Front Lower Control Arm + 2x Front Outer Tie Rod + 2x Front Sway Bar
- Detroit Axle Suspension components are ready to meet the rigorous demands of today's foreign and domestic passenger cars, trucks, and SUVs
- Undergo impact, wear, and fatigue testing to help ensure quality and durability
- 10-Year Warranty
- 【SUSPENSION KIT FOR】 - for ACURA TSX 2004 2005 2006 2007 2008 for Honda for Accord Sedan / Coupe 2003 2004 2005 2006 2007 Fits 2.4L Models ONLY
- 【WHAT INCLUDED】 - 1 x K620616 Front Upper Control Arm And Ball Joint 1 x K620617 Front Upper Control Arm And Ball Joint 1 x K640289 Front Lower Control Arm 1 x K640290 Front Lower Control Arm 2 x K80228 Front Lower Ball Joint
