A14-039
January 28, 2015
00280-01363 Version 2
MIL Comes On with DTC P0087
Supersedes 14-039, dated October 11, 2014, to revise the information highlighted in yellow.
AFFECTED VEHICLES
Year | Model | Trim | VIN Range | ||||||
---|---|---|---|---|---|---|---|---|---|
2014 | Accord | 4-Door – L4 | 1HGCR2…EA054295 to 1HGCR2…EA113613 | ||||||
2014 | Accord | 2-Door – L4 | 1HGCT1…EA004063 to 1HGCT1…EA006033 |
REVISION SUMMARY
Under AFFECTED VEHICLES, 2013 models were added.
SYMPTOM
The MIL is on with DTC P0087 (fuel rail pressure too low).
POSSIBLE CAUSES
An internal component of the high pressure fuel pump causes low fuel pressure.
CORRECTIVE ACTION
Replace the high pressure fuel pump.
PARTS INFORMATION
Part Name | Part Number | Quantity |
Fuel Joint Pipe Set | 16012-5A2-315 | 1 |
Pump Assembly | 16790-5A2-A01 | 1 |
Throttle Body Gasket | 17107-R40-A01 | 1 |
Intake Manifold Gasket | 17115-5A2-A01 | 4 |
Fuel Clip | 17711-S0X-004 | 1 |
WARRANTY CLAIM INFORMATION
The normal warranty applies.
Operation Number | Description | Flat Rate Time | Template ID | Failed Part Number |
1211U6 | Replace the high pressure fuel pump. | 1.6 hours | 14-039A | 16790-5A2-A01 |
Defect Code: 07701
Symptom Code: 03203
Skill Level: Repair Technician
INSPECTION
Check the HDS On-Board Snapshot.
- If the FUEL LEVEL value is more than 3.5% go to REPAIR PROCEDURE.
- If the FUEL LEVEL value is less than or equal to 3.5%, this bulletin does not apply; continue with normal
REPAIR PROCEDURE
NOTE: During the repair, follow the basic procedures listed below. For more detail about any of these procedures, see the electronic service manual.
- Fuel Pressure Relieving (L4).
- Camshaft Timing Inspection (L4).
- Intake Manifold Removal and installation (L4).
- Remove the fuel bracket.
- Remove the EVAP canister purge valve.
- Remove the high pressure fuel pump cover.
- Remove the fuel joint pipe.
- Remove the high pressure fuel pump.
NOTE: Set the No. 1 piston at top dead center (TDC), and then turn the crankshaft 105° counterclockwise before removing the high pressure fuel pump.
- Turn the crankshaft and check the high pressure fuel pump cam for any pitting, scoring, or excessive wear. If needed, replace the fuel pump camshaft.
- Set the No. 1 piston at top dead center (TDC), and then turn the crankshaft 105° counterclockwise. Check the position of the cam that drives the high pressure pump as shown. If the cam position is not correct, continue turning the camshaft until it is.
- Lubricate the cam and roller with clean engine oil, and then install the high pressure fuel pump with the new fuel line clip. Loosely install the bolts.
- Apply the polyethylene glycol that is included with the fuel joint pipe to the areas shown, and then install the new fuel joint pipe.
- Torque the high pressure fuel pump mounting bolts and fuel joint pipe nuts to the specifications shown below.
- Reinstall the parts in reverse order, and then check for any fuel leaks.
END
NHTSA ID Number: 10056640
Manufacturer Communication Number: SB-14-039
Summary
HONDA: HIGH PRESSURE FUEL PUMP INTERNAL COMPONENT CAUSES LOW FUEL PRESSURE AND HIGH PRESSURE FUEL PUMP WILL BE REPLACED. MODEL 2014 ACCORD. *PE
1 Associated Document
Service Bulletin Document
A14-039
October 11, 2014
https://www.nhtsa.gov/recalls?nhtsaId=10056640
SB-10056640-1320.pdf 848.354KB
