November 27, 2014
BTB 00477 (1411)
Buzzing or Static on Receiving End During HFL Call
The HFL microphone is faulty.
Inspect the date code of the HFL microphone and, if needed, replace it.
|Part Name||Part Number||Quantity|
|TSX Microphone Assy.||39182-SMA-003||1|
|ILX Microphone Assy.||39180-TX6-A01||1|
WARRANTY CLAIM INFORMATION
The normal warranty applies.
|Model||Operation Number||Description||Flat Rate Time||Template ID||Failed Part Number|
|ILX||0501A2||Inspect and replace the microphone||0.3 hr||14-046N||39180-TX6-A01|
|TSX||0501A2||Inspect and replace the microphone||0.3 hr||14-046P||39182-SMA-003|
Defect Code: 03217
Symptom Code: 03214
Skill Level: Repair Technician
INSPECTION AND REPAIR PROCEDURE
- Turn off the front individual map light switch.
- Carefully pry off the lenses with a flat-tip screwdriver.
- Remove the two mounting bolts
- Disconnect the connectors, then remove the roof console (ILX) or map light housing (TSX).
- TSX only: Carefully pry off the moonroof switch assembly from the map light housing while pressing in on the retaining tabs.
- Remove the HFL microphone.
- Inspect the side of the microphone. There will be two lines of numbers. The first two characters on the top line is the date code.
NOTE: How to read the date code:
The first character is the YEAR
- = 2011
- = 2012
- = 2013 Etc.
The second character is the MONTH
A = January
B = February
This microphone has a date code of 3L, which means 2013 December.
- If the microphone has a date code of 3J (2013 October) or later, it has the updated design. Do not replace it. Instead, continue with normal troubleshooting.
- If the microphone has a date code earlier than 3J, replace it with a new service part.
- Reinstall all parts in the reverse order of removal.
- Place a test call using HFL, and make sure the map lights and moonroof switch work properly.
