Low Tire Pressure Indicator Stays On, But All Tire Pressures Are OK – 2007-2008 Acura MDX RDX TSX

B07-057
11.16.2007



Applies To:

See VEHICLES AFFECTED



Low Tire Pressure Indicator Stays On, But All Tire Pressures Are OK



PROBABLE CAUSE

The TPMS sensor indicates a lower pressure than the actual tire pressure.



SYMPTOM

The low tire pressure indicator stays on, but all of the
tire pressures are OK.



VEHICLES AFFECTED

2007 MDX ALL
2008 MDX From VIN 2HNYD28..8H500001 thru 2HNYD28..8H510923
2007 RDX ALL
2008 RDX From VIN 5J8TB18..8A000001 thru 5J8TB18..8A003970
2007 TSX ALL
2008 TSX From VIN JH4CL9…8C000001 thru JH4CL9…8C015018



CORRECTIVE ACTION

Replace the faulty TPMS sensor(s).



PARTS INFORMATION

TPMS Sensor 42753-STK-A02



TOOL INFORMATION

Tire Pressure Gauge 07AAJ-000A100



WARRANTY CLAIM INFORMATION

In warranty: The normal warranty applies.

OP# Description FRT
4211A9 Do the diagnosis with the HDS, and replace the TPMS sensor 0.8
A Replace one additional sensor, add 0.4
B Replace two additional sensors, add 0.8
C Replace three additional sensors, add 1.2

Failed Part: P/N 42753-STK-A02
Defect Code: 03217
Symptom Code: 03220
Skill Level: Repair Technician
Out of warranty: Any repair performed after warranty expiration may be eligible for goodwill consideration by the District Parts and Service Manager or your Zone Office. You must request consideration, and get a decision, before starting work.



DIAGNOSIS

  1. Inflate all of the tires to the recommended pressure shown in the doorjamb. Use the recommended tire pressure gauge to make sure the pressures are accurate.
  2. Drive the vehicle until you see the pressure change in the multi-information display (MID).
  3. Check the pressures of all of the tires in the MID. Are all of the tire pressures shown in the MID within 3 psi of what you set them at?
    • Yes – You are finished.
      NOTE: This is not a warrantable repair if the low tire pressure indicator goes off with proper air pressure.
    • No – Go to REPAIR PROCEDURE to replace any sensor that is not within this specification.



REPAIR PROCEDURE

Replace the faulty sensor(s):



Download (PDF, 38KB)
