B07-003
January 19, 2007
Applies To:
2005–06 RL – ALL
2007 RL – From VIN JH4KB1…7C000001 thru JH4KB1…7C001724
Fuel Vapor Lock
SYMPTOM
The engine has an occasional performance problem during unseasonably warm weather. This condition is worse at higher altitudes.
CORRECTIVE ACTION
Replace the fuel pump module. The new fuel pump module has a recalibrated fuel pump.
PARTS INFORMATION
| Fuel Pump Module: P/N | 17708-SJA-A02  |
| Base Gasket: P/N | 17574-SDC-L01 |
WARRANTY CLAIM INFORMATION
In warranty: The normal warranty applies.
| Operation Number: | 3101C7 |
| Flat Rate Time: | 0.6 hour |
| Failed Part: P/N | 17708-SJA-A01 |
| Defect Code: | 03217 |
| Symptom Code: | 09304 |
| Template ID: | 07-003A |
| Skill Level: | Repair Technician |
Out of warranty: Any repair performed after warranty expiration may be eligible for goodwill consideration by the District Parts and Service Manager or your Zone Office. You must request consideration, and get a decision, before starting work.
REPAIR PROCEDURE
Replace the fuel pump module:
NOTE: Do not do step 7 of the replacement procedure.
- Refer to page 11-317 of the 05–07 RL Service Manual, or
- Online, enter keyword PUMP and select Fuel Pump/Fuel Gauge Sending Unit Replacement from the list.
